ZM301 Weight Indicator

The ZM301 weight indicator features a highly visible display that can be viewed from a distance in low and brightly lit environments. This high contrast, 0.8” (20 mm) high-digit IBN display provides excellent color contrast and enhanced viewing angles, reducing operator error and improving productivity.

Designed to ensure compatibility and communication between old and new peripheral technologies, the ZM301 has multiple serial ports, a USB port, and an Ethernet socket that can be configured to support a number of independent devices, both DHCP client and server, and monitors/captures key weight data in the background. The ZM301 is able to connect to PCs, PLCs, printers, scanners, relays and remote displays, ensuring a controlled process.

The ZM301 can hold one option card internally to provide more flexibility to the indicator to work within a required process. The options cards that can be used are:

Analog output
Current Loop/RS485/RS422
USB Device
Internal Wireless 802.11b/g

Simple to operate while remaining fully flexible to print and record a wide range of weight data. The ZM301 offers predefined print formats that can be modified to meet printing requirements.

This 10,000d legal for trade approved, single base indicator provides outstanding weighing accuracy, perfect for any business that trades by weight. It is designed to connect up to most bench scales, floor scales or hoppers with up to 6 x 350ohm load cells. Approved for use in a wide range of global regions (NTEP /Measurement Canada, UK/EC/OIML).
